Category

Embedded Power

Server Power Networking Power Telecom Power
ASIC Power

All-in-one Machine Power Supply Discrete Power Supply
Small-power Storage Power Supply

48Vdc Seires Fan Cooling Power Supply
Energy Storage and PV&EV Energy Conversion

Bidirectional DC-DC Converter

Fan Cooling Power Suppy

BOCO provide high protection level fan cooling power supply and the products have been proved in touch environments with high temperature, high humidity, extremely low temperature, and high pollution degree, with lower than 3000ppm filed failure ratio.

Model Name	Inlet Socket	Input Voltage	Output Voltage(V)	Max Output Current(A)	Auxilary Output	Operating Temperature (℃)	Dimension (mm^3) LxWxH	Remark
BCJ75002-01	C20, x2	220-240VAC	11.5V-15V	Liquid cooling 598.4A Fan cooling 416.7A	-	Liquid cooling 0～80℃ Fan cooling -40～53℃	253 x 249 x 63.3	I2C
BCJ47003-01	dual C20	220-240VAC	10-15V	370A	48V/12V 4.37A/1.67A	-20～45	250x 254 x 63.3	I2C
BCJ36002-12	C20	220-240VAC	10.5-14.5	300	12.3V/20A	-40 ~ 70	300x131x71	I2C
BCJ36002-13	C20	220-240VAC	11.5-15.5	280	12.3V/20A	-40 ~ 70	300x131x71	I2C
BCJ36002-10	C20	220-240VAC	10.5-14.5V	300	12.3V/20A	-40 ~ 70	300x131x71	I2C
BCJ36002-14	C20	220-240VAC	11.5-15.5	280	12.3V/20A	-40 ~ 70	300x131x71	I2C
BCJ36002-16	PA45	220-277VAC	10.5-14.5	300	12.3V/20A	-40 ~ 70	300x131x71	I2C
BCJ36002-17	PA45	220-277VAC	11.5-15.5	280	12.3V/20A	-40 ~ 70	300x131x71	I2C
BCJ36002-11	PA45	220-277VAC	10.5-14.5	300	12.3V/20A	-40 ~ 70	300x131x71	I2C
BCJ36002-15	PA45	220-277VAC	11.5-15.5	280	12.3V/20A	-40 ~ 70	300x131x71	I2C

3/10

View all

Liquid Cooling Power Supply

BOCO's liquid cooling power supply are compatible with various liquid. Wide range output voltage and up to 96% full load efficiency helps customer shorten the product development time.

Model Name	Inlet Socket	Input Voltage	Output Voltage(V)	Max Output Current(A)	Auxilary Output	Operating Temperature (℃)	Dimension (mm^3) LxWxH	Remark
BCJ52002-02	ECBT2.E319259 PA45	220-240VAC	11.5-15.5V	433	12.3V/2.5A	0～60℃	222.0 x 214.8x 63.3	I2C
BCJ50002-01	C20	220-277VAC	11.5-16.5V	434	12V/2A	0～70℃	300 x 131 x 71	I2C
BCJ90002-01	SA2-30	380-480VAC	21-31	427	7V/3A	-20-70	364x258.5x44.5	I2C

3/3

Water Cooling Power Supply

BOCO's water cooling power supply provides wide range output voltage and up to 96.5% efficiency to help customer shorten the product development time.

Model Name	Inlet Socket	Input Voltage	Output Voltage(V)	Max Output Current(A)	Auxilary Output	Operating Temperature(℃)	Dimension (mm^3) LxWxH	Remark
BCJ100002-01	SA2-30	380-480VAC	31-47V	300A	7V/4A	Up to 70	487.7 x 140 x 72	I2C

1/1
