| Output Power | 2000 W |
| AC side voltage | 120 VAC |
| DC side voltage | 32VDC |
| Rectifier Mode Input voltage range | 90-140VAC |
| Rectifier Mode Input current | 0-15A |
| Rectifier Mode main output voltage | 32VDC |
| Rectifier Mode main output current | 50A |
| Rectifier Mode efficiency | 95% |
| Inverter Mode Input voltage range | 27-37.8V |
| Inverter Mode Input current | 0-75A |
| Inverter Mode main output current | 120VAC |
| Inverter Mode efficiency | 95% |
| Dimension(LxWxH) | 262x202x59.6(mm) |
| Weight | 3.0Kg |
| Cooling | Natural air Cooling / Fan Cooling |
| Input Socket | C6201AV-3P |
| Output socket | XT60/C6201AF-2P/C6201AV-2P |
| Operating Temperature | -10 ~ 40℃ |
| Storage Temperature | -20-75℃ |
| Operating Humidity | 0% ~ 90% |
| Altitude | 3000m |
| Safety | UL1778 |
| EMI | Class B |
| Communication | RS485 |
| Control | Digital Control |
| Protection | Over voltage, over current/short circuit, over power, over temperature |
| MTBF | 100K |
